This guide provides the main technical parameters of the NC8 series alternating current contactors, including rated voltage, current, temperature limits and mechanical dimensions. It also describes the control circuit capabilities, auxiliary contacts and optional accessories.
The document includes tables of rated currents for various voltage levels, wiring diagrams, and information on derived products such as reversible contactors and timing modules. Installation notes and environmental requirements are also covered. This manual is written in Chinese.
| Rated voltage | 690 V |
|---|---|
| Rated frequency | 50 Hz/60 Hz |
| Maximum continuous current | 100 A |
| Altitude rating | up to 2000 m |
The NC8 series contactor is rated for up to 690 V.
It can handle continuous currents up to 100 A, depending on the model.
Both 50 Hz and 60 Hz AC supply frequencies are supported.
