The PI965GME-M motherboard is a Mini-ITX motherboard that supports Socket P Intel® CoreTM 2 Duo Mobile processors. It features support for Windows operating systems, built-in audio functionality, expansion slots, IDE and SATA hard drive connectors, and more.
This manual covers the hardware layout, supported components, and step‑by‑step installation procedures for the Asus PI965GME-M Mini‑ITX motherboard. It includes safety guidelines, component diagrams, and detailed instructions for CPU, memory, and peripheral installation.
Additional sections explain BIOS configuration, driver installation for Windows Vista/XP/2000, and audio channel setup. Appendices provide channel‑selection instructions and driver CD usage. This manual is written in Chinese.
| CPU Socket | Socket P |
|---|---|
| Supported CPUs | Intel Core 2 Duo Mobile |
| SATA Ports | 3 × SATA 2.0 (3 Gb/s) |
| IDE Ports | 1 × Ultra ATA 33/66/100 |
| USB Ports | 4 rear USB 2.0/1.1 ports, 2 front headers (expandable to 8) |
It supports Intel Core 2 Duo Mobile processors that use the Socket P package.
Four USB 2.0/1.1 ports are on the rear panel, with two front headers that allow up to eight ports total.
