JS11S series time relay is suitable for AC 50/60Hz, rated control power supply voltage below 380V or DC 24V control circuit for time control element, according to the preset time to connect or disconnect the circuit. The product meets the requirements of JB/T10047, GB14048.5, IEC60947-5-1 standard.
This document describes the JS11S series time relay, suitable for AC 50/60 Hz control circuits with voltage up to 380 V or DC 24 V. It outlines the relay’s operating conditions, environmental limits, and compliance with standards such as JB/T10047, GB14048.5 and IEC60947‑5‑1.
The manual includes wiring diagrams, adjustment procedures, mechanical and electrical specifications, and safety precautions. It also provides ordering information and details on the relay’s reset, pause, and memory functions. This manual is written in Chinese.
| Rated Control Voltage | AC 380 V (50/60 Hz) or DC 220 V |
|---|---|
| Time Delay Range | 0.1 s ~ 9.9 s, 1 s ~ 99 s, 1 min ~ 99 min, etc. |
| Contact Capacity | AC 220 V 3 A |
| Maximum Installation Altitude | 2000 m |
Installation altitude should not exceed 2000 m.
Signal input lines should not be bundled with high‑current wires, should use shielded cable, and be kept short to avoid interference.
