The HXMJ-302 series product is a router based on G.shdsl technology that transmits high-speed digital signals and multimedia information over twisted pair cables. The device can be conveniently connected to a Switch, Hub or computer.
This manual describes the HXMJ-302 series routers produced by Huazuan. It covers the different model variants (HXMJ-302‑1 to HXMJ-302‑4), their interface configurations, and the layout of the front panel with all status LEDs.
The document also explains how to connect power, Ethernet and SHDSL interfaces, and provides a troubleshooting section that interprets the meaning of the indicator lights and common fault conditions. This manual is written in Chinese.
| HXMJ-302-1 Ethernet interfaces | 1 |
|---|---|
| HXMJ-302-1 DSL interfaces | 1 |
| HXMJ-302-2 Ethernet interfaces | 2 |
| HXMJ-302-2 DSL interfaces | 2 |
| HXMJ-302-3 Ethernet interfaces | 3 |
| HXMJ-302-3 DSL interfaces | 3 |
| HXMJ-302-4 Ethernet interfaces | 4 |
| HXMJ-302-4 DSL interfaces | 4 |
The HXMJ-302-3 model has three Ethernet interfaces.
The LINK light shows the SHDSL link status; it flashes when the link is being established and stays solid when the connection is successful.
If the PWR LED is off, verify that the power cable is correctly connected and that the power supply is functioning.
