The MS 6508 motherboard supports one or two 603‑pin Intel Xeon processors and uses Intel 82860, 82803AA, 82801BA, and 82806AA chipsets. It offers eight RAMBUS slots for 128 MB or 256 MB dual‑channel PC800 ECC modules, an AGP 4X slot, multiple PCI slots, IDE, USB, integrated Intel 82550 NIC, AC97 audio, and an Adaptec Ultra‑160 SCSI controller.
The guide details CPU and memory installation, jumper settings for clearing CMOS, fan connector usage, driver installation for Windows 98/2000/NT, and step‑by‑step procedures for installing the integrated SCSI card and configuring network wake‑on‑LAN and alert‑on‑LAN features. This manual is written in Chinese.
| Supported CPUs | One or two 603‑pin Intel Xeon processors |
|---|---|
| Memory Controller | Intel 82860 |
| Memory Repeater Hub | Intel 82803AA |
| I/O Controller Hub | Intel 82801BA (ICH20ZO) |
| PCI Controller | Intel 82806AA (64‑bit) |
| RAMBUS Slots | 8 slots, 128 MB or 256 MB dual‑channel PC800 ECC |
| AGP Slot | Accelerated Graphics Port 4X |
| MECC Slot | Memory expansion connector |
| IDE Interface | ATA 33/66/100, up to 8 devices |
| USB Ports | 2 × USB 1.1 |
| Integrated Ethernet | Intel 82550 NIC |
| Integrated Audio | AC97 codec |
| Wake‑On‑LAN Header | JWOL1001 |
| Alert‑On‑LAN Header | JAOL1000 |
It supports one or two 603‑pin Intel Xeon processors.
The board accepts 128 MB or 256 MB dual‑channel PC800 ECC RAMBUS modules in its eight RAMBUS slots.
Windows NT4, Windows 2000, and Windows XP Professional support dual CPUs; Windows 98, Windows ME, and Windows XP Home do not.
