The guide explains how to install and configure the Lenovo Intel Pro/100 S network adapter, including driver installation, license agreement acceptance, and troubleshooting tips. It also describes the LED indicators that show link status and activity.
Additional sections cover the adapter's technical specifications such as PCI version, supported Ethernet standards, transmission rates, operating temperature range, safety certifications, and advanced features like checksum offload and IP security support. This manual is written in Chinese.
| PCI version | V2.2 |
|---|---|
| Network interface | RJ45 |
| Supported Ethernet | 100Base TX Fast Ethernet |
| Transmission rate | 10 M or 100 M |
| Operating temperature | 0 °C ~ +85 °C |
| LED indicators | Activity/Link, 100 Mbps |
| Safety certification | UL |
| FCC class | Class B |
| CE & Immunity | Yes |
| Checksum offload | TCP/UDP/IPv4 |
| IP security support | Enabled |
Run the provided Setup.exe program, accept the license agreement, follow the default options, and restart the computer after installation.
The ACT/LNK LED stays on when the link is normal; it is off when there is no connection or a problem with the adapter or cable.
