AD2150 series matrix switching/control system is a control system for closed-circuit television monitoring system, which can control up to 32 video input sources and up to 5 video outputs. It can also control multiple control stations (keyboards).
The AD2150 series is an integrated matrix switch and control system for CCTV monitoring, supporting up to 32 video inputs and multiple video outputs, as well as up to five video monitors and several control stations. The system can be expanded with additional keyboards (AD2078/AD2079) and auxiliary devices.
The manual describes keyboard functions, monitor selection, lens control, audio indicators, alarm handling, group programming, and auxiliary control. It also lists the available ports (RS‑232, BNC, dual‑line keyboards) and explains how to program and operate the system for video switching, camera tours, and remote control of PTZ cameras. This manual is written in Chinese.
| Video input ports | 32 (75Ω) |
|---|---|
| Video output ports | 75 (75Ω) |
| RS‑232 ports | 3 (8‑pin) |
| Dual‑line keyboard inputs | 4 |
| Control code outputs | 4 |
| Format C contacts (relays) | 4 |
| Synchronous inputs | 4 |
The AD2150 provides 32 video input ports (75Ω).
The system includes three 8‑pin RS‑232 ports.
