ZQL9712 chip is a chip designed for LED driver applications, with features such as low power consumption and optimized interface for multi-chip cascading applications.
The ZQL9712 LED driver chip is designed for LED display systems, providing three high‑current driver outputs (up to 30 mA) and a row latch that converts inputs to a 3‑bit parallel output. It operates with a low‑power CMOS process and includes separate clock controls for the row and output latches.
The device is offered in multiple packages (DIP, DIE, COB1, COB2, TSSOP) and features a 5 V CMOS supply, 15 MHz clock, 600 mW power dissipation, and an operating temperature range of –40 °C to +85 °C. Electrical characteristics such as VDD, VOUT, VIN, and IOUT are detailed in the datasheet. This manual is written in Chinese.
| Supply voltage (VDD) | 5 V CMOS |
|---|---|
| Clock frequency (FCLK) | 15 MHz |
| Power dissipation (PD) | 600 mW |
| Operating temperature range | -40 °C to +85 °C |
| Output voltage range (VOUT) | -0.5 V to +0.5 V |
| Input voltage range (VIN) | -0.4 V to VDD+0.4 V |
It operates from a 5 V CMOS supply.
The chip is offered in DIP, DIE, COB1, COB2, and TSSOP packages.
