This manual covers the operation, installation, and maintenance of the Midea CXW‑218‑EA61/EA62/EA63 range hood. It includes safety information, wiring diagrams, and a parts list for proper assembly.
The document also provides detailed technical specifications, a list of accessories, and a troubleshooting section that helps resolve common faults such as lamp failures, motor issues, and mounting problems. This manual is written in Chinese.
| Power Supply | 220V~50Hz |
|---|---|
| Motor Input Power | 218W |
| Lighting Power | ≤20W×2 |
| Air Flow (Hurricane) | 17.5±1 m³/min |
| Air Flow (Strong Wind) | 15.5±1 m³/min |
| Air Flow (Quiet) | 10.0±1 m³/min |
| Maximum Static Pressure | ≥310 Pa |
| Noise (Hurricane) | 56/70 dB |
| Noise (Strong Wind) | 54/68 dB |
| Noise (Quiet) | 44/58 dB |
| Dimensions | 750 mm × 494 mm × 485 mm |
| Finish | Brushed stainless steel, pearl white, silver |
Tighten the mounting brackets and motor fixing screws.
Adjust the hood to a suitable height; avoid installing it too high.
