This is the TL1 62 & TL1 92 cooker hood user manual. The manual includes the features and characteristics of the cooker hood, instructions for use, cleaning and maintenance, technical specifications, installation and troubleshooting.
This manual introduces the Midea TL1 62 and TL1 92 range hoods, describing their design features such as motor controllers, lighting, removable metal filters, and optional carbon filters. It explains how to operate the hood using the control buttons and recommends pre‑cooking ventilation.
Detailed sections cover safe installation, required clearances, vent hose limits, cleaning procedures for the metal filter, body, and lighting, replacement of carbon filters and lamps, technical specifications, and a troubleshooting guide for common issues such as a non‑working fan or reduced suction. This manual is written in Chinese.
| Width | 600/900 mm |
|---|---|
| Depth | 280 mm |
| Height | 181 mm |
| Maximum Lamp Power | 40 W |
| Minimum clearance to electric stove | 60 cm |
| Minimum clearance to gas stove | 65 cm |
| Maximum exhaust outlet pressure | 4 Pa |
| Maximum vent hose length | 4 m |
| Maximum number of 90° bends in vent hose | 2 |
Check that the main power line is connected to the circuit and that the plug is inserted into the socket.
The metal filter should be cleaned at least once a month, depending on usage frequency.
The lamp can have a maximum power of 40 W.
