TCZ-H precision temperature controller user manual. Suitable for high precision temperature control of thermostatic bath and can be used for calibration of first-grade and second-grade standard platinum resistors.
This manual describes the TCZ-H precise temperature controller, its high‑resolution measurement (0.01 °C) and accuracy (0.1 °C) for laboratory and industrial use. It outlines the supported temperature sensors (PT100, etc.), communication options, and power requirements.
The document includes detailed panel function descriptions, parameter setting procedures, signal output configurations (4‑20 mA, 0‑5 V), and mechanical dimensions (80 × 160 mm). It also provides a full parameter table and wiring information for installation and troubleshooting. This manual is written in Japanese.
| Measurement resolution | 0.01 °C |
|---|---|
| Measurement accuracy | 0.1 °C |
| Power supply | 220 V 50/60 Hz |
| Communication baud rate | 9600 bps |
| Output signal (current loop) | 4‑20 mA |
| Physical dimensions (panel) | 80 × 160 mm |
The instrument provides a measurement accuracy of 0.1 °C.
The panel size is 80 mm by 160 mm.
The controller communicates at a baud rate of 9600 bps.
It provides a standard 4‑20 mA current‑loop output.
