This document is a manual for 1/4 -DIN, 1/8 -DIN, and 1/16 -DIN controllers, display instruments, and program controllers. It provides information on installation, option modules, wiring, power-on, operation modes, etc.
The Danaher 1/4‑DIN, 1/8‑DIN and 1/16‑DIN controllers are compact DIN‑rail mounted devices for process control, offering analog and digital I/O, PID control and communication interfaces. The manual covers safety information, power requirements, wiring, module configuration and troubleshooting.
Key sections include safety guidelines, power supply details, input and output module wiring, RS485/Modbus communication setup, PID parameter settings, and a full list of specifications and certifications. The document also provides wiring diagrams and functional tables for each controller size. This manual is written in Chinese.
| Input voltage (AC) | 100‑240 VAC, 50/60 Hz |
|---|---|
| Input voltage (DC) | 24‑48 V AC/DC |
| Dimensions (1/16‑DIN) | 45 mm × 45 mm |
| Dimensions (1/4‑DIN) | 92 mm × 92 mm |
The controllers can be powered from 100‑240 VAC (50/60 Hz) or from a 24‑48 V AC/DC source.
The devices support RS485 Modbus RTU and ASCII communication interfaces.
The 1/16‑DIN module measures 45 mm × 45 mm, the 1/8‑DIN module 45 mm × 92 mm, and the 1/4‑DIN module 92 mm × 92 mm.
