QPY-6255A LCD display control board is designed and produced around the MSM6255 LCD display controller. While fully utilizing the advantages of MSM6255, it improves the peripheral circuit of MSM6255 and enhances the interface performance between MSM6255 and the single-chip microcomputer system, making QPY-ENH6255 LCD display control board a dedicated control board for large screen LCD display modules in single-chip microcomputer systems.
The QPY-6255A LCD Control Board is designed around the MSM6255 LCD controller and offers a 64K‑byte display buffer, 4‑level grayscale, and a robust CPU interface with an 8‑bit data bus and five control lines. It supports various monochrome and STN color LCD modules up to 640×480 resolution and includes contrast adjustment and a compact 113×77 mm form factor.
The manual details the board’s hardware description, electrical characteristics, MPU and LCD module pin definitions, command set, and provides programming examples for both direct and indirect MCU control. Appendices list compatible LCD modules and service information. This manual is written in Chinese.
| Display buffer size | 64K bytes |
|---|---|
| CPU interface | 8‑bit data bus, 5 control lines (CS, RS, /WR, /RD, BUSY) |
| Supply voltage | 5 V (single +5 V) |
| Operating voltage range | 4.5 V – 5.5 V |
| Dimensions | 113 mm × 77 mm |
The board operates from 4.5 V to 5.5 V.
It provides a 64 KB display buffer.
It offers an 8‑bit data bus and five control lines (CS, RS, /WR, /RD, BUSY).
