This manual introduces the product features, performance parameters, installation and use precautions of GMSP-007VS, GMSP-007AO car-mounted TFT-LCD displays.
This manual describes the 7.0" TFT‑LCD car display, its 16:9 aspect ratio, 250 nits brightness, and support for PAL/NTSC/SECAM video standards. It lists the supplied accessories such as remote control, steel brackets, and wiring cables, and highlights features like anti‑radiation, low power consumption, and infrared audio transmission.
The guide includes safety warnings, installation steps, wiring diagrams, remote‑control operation, and bracket adjustment instructions. It explains how to switch video inputs (V1/V2), adjust picture orientation, and what to expect when no signal is detected (blue screen and automatic shutdown). This manual is written in Chinese.
| Screen size | 7.0 inches |
|---|---|
| Display ratio | 16:9 |
| Power supply | DC 12 V |
| Brightness | 250 nits |
| Video input | V1 / V2 |
| Operating temperature | -10 °C to +60 °C |
| Storage temperature | -20 °C to +70 °C |
| Resolution | 480 × 234 |
| Supported video standards | PAL, NTSC, SECAM |
No, the manual warns that the unit must not be installed in the driver’s seat or directly in front of the front passenger seat.
Use the remote control or the on‑device buttons to select video input V1 or V2.
The display shows a blue screen and automatically powers off after a few minutes.
