SKY-TX24017 wireless audio and video module is a FM audio and video transmission module working in the 2400-2480MHz ISM band. It adopts a single-chip design. The characteristics are small size, low power consumption, high sensitivity, and easy to use. Just connect the power supply, single/dual audio cable, video cable, and antenna to receive music and image signals.
This manual introduces the SKY-TX24017 wireless audio/video module, which operates in the 2400‑2480 MHz ISM band and offers 2.4 GHz wide‑band FM transmission. The module is compact (23 × 18 × 4.5 mm), low‑power (100 mA) and supports four transmission channels.
The document details electrical characteristics, connection methods (power, audio, video, antenna), application circuits, and mechanical dimensions, enabling users to set up the module for applications such as wireless audio/video streaming, security transmission, and video monitoring. This manual is written in Chinese.
