P601P-MP-V01 Stepping Servo Motor Single-Axis Programmable Controller User Manual, including product name, model, function, usage method, installation instructions and other content.
This manual describes the Sunholy P601P stepping servo motor single‑axis programmable controller, covering its hardware layout, signal connections, and operating modes. It is intended for users who need to install, configure, and maintain the device.
The document includes component identification, connector pin assignments, switch functions, specifications, internal circuit diagrams, data‑setting procedures, external control options, test mode usage, mechanical dimensions, installation opening drawings, and wiring examples. This manual is written in Chinese.
| Power Supply | DC 24 V, 7100 mA |
|---|---|
| Operating Temperature | 0 °C to +40 °C |
| Input Signal | DC 24 V optocoupler, input impedance 4.7 kΩ |
| Output Signal | DC 24 V optocoupler, output current 25 mA |
| Pulse Speed (run) | 35 – 59 995 PPS |
| Pulse Speed (start) | 35 – 9 995 PPS |
| Acceleration/Deceleration Time | 1 – 9 999 ms |
The controller requires a DC 24 V power supply capable of delivering up to 7100 mA.
Input signals are DC 24 V optocoupler inputs with an input impedance of 4.7 kΩ.
The device operates from 0 °C up to +40 °C.
