The EC1800 fixed infrared thermometer is a non-contact temperature measurement instrument with a measurement range of 600℃-1800℃ and an accuracy of full scale 1% and repeat accuracy of full scale 0.3%. The main functions include upper and lower limit setting and over limit alarm function, maximum value display function, over and under range indication function.
The EC1800 is a fixed‑type non‑contact infrared thermometer that measures temperature by detecting emitted infrared energy. The device includes a detector, signal processing circuitry, and a control box that displays temperature readings and provides alarm functions.
The manual provides wiring diagrams, connection details for 4‑20 mA, RS‑485 and voltage inputs, as well as specifications such as measurement range, accuracy, emissivity settings, power requirements, and troubleshooting guidance. This manual is written in Chinese.
| Measurement range | 0.2‑1.0 m |
|---|---|
| Accuracy (partial scale) | ±0.3 % |
| Output signal | 4‑20 mA DC (max 250 Ω) |
| Power supply | 220 V AC 50 Hz |
| Control box temperature range | -0 °C to 50 °C |
| Detectable object temperature range | -0 °C to 60 °C |
The EC1800 can measure temperatures from 0.2 m to 1.0 m distance.
It provides a 4‑20 mA DC output (maximum load 250 Ω) and RS‑485 interfaces.
Wipe the surface with a soft cloth dampened with mild detergent; avoid abrasive cleaners.
