The guide explains how to install the UW-122AS-2 water cooler, covering safety precautions, power requirements, pipe connections, and proper positioning. It also describes the control panel functions, such as temperature selection, water‑quality testing, and the re‑boiling feature.
Additional sections detail fault indicators, regular maintenance tasks, warranty information, and a pipe diagram with specifications for pressure ratings and recommended materials. The document ends with a brief list of the cooler’s key features. This manual is written in Chinese.
| Water pressure range | 0.7–5 kg/cm² |
|---|---|
| Pipe pressure rating | ≥10 kg/cm² |
| Power outlet load | ≥15 A |
| Maximum extension cable length | 15 m |
Wait until the “缺水” warning light stops flashing; the function keys cannot be used until the light turns off.
Press the re‑boiling key; the indicator lights up and the system heats to 100 °C, then automatically stops after the cycle.
