7010NET 10/100/1000M PCI Express Ethernet Card is a 1000Mbps Ethernet card. It supports PCI Express 1.0a standard, automatically adapts to 10/100/1000Mbps speed, supports full-duplex half-duplex working mode, supports remote wake-up and diskless boot, and supports multiple network operating systems.
This manual provides step‑by‑step instructions for installing the 7010NET 10/100/1000M PCI Express Ethernet card in a computer chassis, connecting the card to the PCI‑Express slot, and securing it with screws. It also describes the required driver installation for supported operating systems such as Windows 98/ME/NT/2000/XP, Windows CE, NetWare, Linux, SCO UNIX and FreeBSD.
The document details the card’s features, including full‑duplex/half‑duplex operation, supported data rates, LED indicators (LNK/ACT), and environmental specifications. Troubleshooting guidance is provided for common issues like the card not being detected or LED indicators not lighting. This manual is written in Chinese.
| Supported data rates | 10Mbps, 20Mbps, 100Mbps, 200Mbps, 1000Mbps, 2000Mbps |
|---|---|
| Operation mode | Full‑duplex and half‑duplex |
| Operating temperature | 0 °C to 55 °C |
| Storage temperature | -20 °C to 70 °C |
| Operating humidity | 10 % to 90 % |
| Storage humidity | 10 % to 90 % |
| LED indicators | LNK/ACT |
Open the computer case, insert the card into an available PCI‑Express slot, and secure it with the screw as described in the hardware installation steps.
The LNK LED shows link status, and the ACT LED indicates activity on the 1000 M connection.
Check that the card is properly seated in the PCI‑Express slot and reinstall it if necessary; if the problem persists, replace the PCI‑Express slot.
