This document is about DG5000 series Function/Arbitrary Waveform Generator, introducing the features of this product.
The DG5000 series is a multifunctional signal generator that combines function generation, arbitrary waveform generation, IQ baseband/IF source, optional frequency hopping and pattern generation. It is available in single‑ and dual‑channel models with up to 350 MHz output frequency and 1 GSa/s sample rate.
The guide is organized into chapters covering quick start, basic and arbitrary waveform output, common modulation, IQ modulation, frequency sweep, burst, frequency‑hopping, store/recall, advanced operations, remote control, troubleshooting, specifications and appendices. Safety requirements, handling, and warranty information are also included.
| Maximum Frequency | 350 MHz (single‑channel), 250 MHz, 100 MHz, 70 MHz (other models) |
|---|---|
| Sample Rate | 1 GSa/s |
| Resolution | 1 µHz |
| Accuracy | ± 1 ppm (18 °C – 28 °C) |
| Harmonic Distortion | ≤ ‑45 dBc up to 100 MHz |
| Standard Waveforms | Sine, Square, Ramp, Pulse, Noise, etc. |
| Channel Options | Single‑channel or dual‑channel models |
The instrument provides a Store and Recall function that lets you save waveform data and instrument state settings and later retrieve them as needed.
The single‑channel DG5000 models can output up to 350 MHz, while other variants support maximum frequencies of 250 MHz, 100 MHz, or 70 MHz.
