D610 embedded ZigBee wireless communication module is a module that integrates a radio transceiver and a microprocessor that complies with the ZigBee protocol standard. It has the advantages and characteristics of long communication distance, strong anti-interference ability, flexible networking, reliable and stable performance. It can realize transparent transmission of data between devices in point-to-point, point-to-multipoint, and multipoint-to-multipoint. It can form star, tree, and honeycomb mesh network structures.
This manual introduces the D610 embedded ZigBee wireless communication module, describing its features such as long‑range transmission, strong anti‑interference capability, flexible networking (star, tree, mesh) and support for point‑to‑point, point‑to‑multipoint and multipoint data communication. It explains the three device roles—coordinator, router and end node—and how they differ only in software configuration.
The document details technical specifications (e.g., transmission distance 100 m–2000 m, receive sensitivity –94 dBm, transmit power –27 dBm to –25 dBm), interface pinouts, power requirements (standard 5 V, normal range 9–12 V), and provides wiring diagrams, configuration settings, installation dimensions, and LED status indicators for data, run, network and alarm functions. This manual is written in Chinese.
| Transmit power | -27 dBm to -25 dBm |
|---|---|
| Antenna connection | External SMA or PCB antenna |
The module provides four LED indicators for data transmission, system run status, network status, and alarm.
The D610 module includes a power interface, RS‑232 and TTL data interfaces, control lines, system indicator lines, and an antenna connector.
