TOP 2011 Universal Programmer Programming Manual

TOP2011 is a general-purpose programmer with small size, low power consumption and high reliability. It is designed for developing single-chip microcomputers and burning various storage devices.

TOP 2011 Universal Programmer Programming Manual - cover page
Brand
TOP2011
Category
Other Electronics
Document type
Programming Manual
Language
Chinese
Pages
16
File format
PDF
File size
151 KB
Published
06 March, 2012
Updated
30 September, 2023
MD5 checksum
EBFFD51099A745713331C78C0492209D
PDF
TOP 2011 Universal Programmer Programming Manual PDF

About this manual

The TOP 2011 is a compact, low‑power universal programmer designed for programming various memory devices. It features a USB interface for high‑speed data transfer and includes over‑current protection to safeguard both the programmer and the target devices.

The manual provides an introduction, performance specifications, a comprehensive list of supported chips, and details of the package contents. It also explains the software requirements (Windows 7/Vista/XP) and optional external power options. This manual is written in Chinese.

What's inside

  • Introduction
  • Performance and Specifications
  • Supported Devices
  • Package Contents

Specifications

Dimensions115 x 90 x 273 mm
Weight175 g
Power Consumption< 2.5 W (5 V/500 mA)
Socket Type40‑pin universal socket

Frequently asked questions

What power sources can the TOP 2011 use?

It can be powered via the USB interface or an external 5 V/1 A supply.

Which operating systems are supported by the TOP 2011 software?

The software runs on 32‑bit Windows 7, Vista, and XP.

How many pins does the programmer’s socket have?

It has a 40‑pin universal socket.
