Oceanspace S2600 is a storage product launched for the mid-to-low end storage market. It integrates innovative architectural design concepts, simple management, energy saving and environmental protection, and provides economical storage solutions and complete data protection measures.
The manual introduces the Oceanspace S2600 storage system, highlighting its seamless integration of FC SAN and iSCSI, high availability (99.999% uptime), and energy‑saving technologies such as disk sleep and low‑power components. It describes the system’s scalability, supporting up to 96 drives, 256 hosts, and various RAID levels for robust data protection.
Technical details cover hardware components (6‑core processor, configurable cache, dual‑controller options), physical dimensions (2U, 861 mm × 446 mm × 536 mm, <20 kg), power options (AC 100‑240 V or DC –48 V to –60 V), and management features including web remote login, multi‑path support, and extensive alarm mechanisms (sound/light, email, SMS, SNMP). This manual is written in Chinese.
| Storage Processor | 6‑core multi‑processor |
|---|---|
| Cache | 2 GB (single controller) or 4 GB/8 GB (dual controller) |
| Controller Quantity | 1 or 2 |
| Maximum Hard Disk Number | 96 |
| Disk Density per Frame | 12 disks per frame |
| Supported Host Ports | Up to 8 × 4 Gb FC, 4 × 4 Gb FC, 4 × 4 Gb SAS, 2 × 4 × 3 Gb iSCSI, etc. |
| Maximum Connected Hosts | 256 |
| Maximum LUNs | 512 |
| RAID Levels Supported | 0, 1, 3, 5, 6, 10, 50 |
| Power Supply Options | AC 100‑240 V (50/60 Hz) or DC –48 V to –60 V |
| Power Consumption | Controller enclosure <340 W, Disk enclosure <230 W |
| Dimensions | 2U, 861 mm × 446 mm × 536 mm |
| Weight (without disks) | <20 kg |
| Operating System Compatibility | Windows, Linux, Solaris, HP‑UX, AIX, VMware, XenServer |
| Management Interface | ISM management console |
| Alarm Methods | Sound/light, email, SMS, SNMP |
| Remote Management | Web remote login and modem dial‑up |
The S2600 can accommodate up to 96 hard drives.
RAID 0, 1, 3, 5, 6, 10, and 50 are supported.
It works with Windows, Linux, Solaris, HP‑UX, AIX, VMware, and XenServer.
