WH8004A temperature meter is a product produced by SUNSTAR Sensor and Control. The product size is 109*45*24mm, the temperature measurement range is -50℃～300℃, and the temperature measurement error is ±0.5℃.
The SUNSTAR WH8004A manual presents the key specifications of the temperature sensor, including its operating temperature range, reference temperature, and sensor type. It also lists the electrical parameters such as output voltage and maximum current.
Contact information for SUNSTAR, including website, telephone, fax and email, is provided on each page for further support.
| Operating temperature range | -50°C ~ 300°C |
|---|---|
| Reference temperature | +40.5°C |
| Sensor type | NTC (100K/3977) |
| Output voltage | 1.5 V |
| Maximum current | 4 µA |
| Storage temperature range | -10°C ~ 60°C |
The sensor operates from -50 °C to 300 °C.
It uses an NTC thermistor with a resistance of 100 kΩ at 25 °C (100K/3977).
The sensor provides an output voltage of 1.5 V.
The maximum current is 4 µA.
