This document is the user manual for YA3060 outdoor PTZ (Pan-Tilt-Zoom) camera. It provides installation and usage instructions, as well as safety precautions.
This manual provides safety precautions, product features, technical specifications, and step‑by‑step installation instructions for the YA3060 outdoor PTZ cloud platform. It also includes wiring diagrams and adjustment procedures to ensure reliable operation in harsh environments.
The document is organized into two main parts: the first introduces the cloud platform, its patented cable routing, motor, gearbox, and protective housing; the second details pre‑installation checks, mechanical structure, mounting, wiring, and limit adjustments. This manual is written in Chinese.
| Operating Voltage | AC24V / AC220V 50‑60Hz |
|---|---|
| Power Consumption (24V) | ≤38 W |
| Power Consumption (220V) | ≤40 W |
| Heating Power | 30 W (220V/24V) |
| Horizontal Rotation Range | 0° ~ 355° |
| Vertical Rotation Range | +10° ~ -90° |
| Maximum Load | 17 kg |
| Maximum Torque | 60 Nm |
| Transmission | Gear reduction drive |
| Ingress Protection Rating | IP66 |
| Operating Temperature | -20 °C ~ 55 °C |
| Dimensions (L×W×H) | 214 mm × 289 mm × 290 mm |
| Weight | 9.5 kg |
The platform can support a maximum load of 17 kg.
It is rated IP66, providing protection against dust and water.
The device operates from –20 °C up to 55 °C.
It can be powered by AC24V or AC220V at 50‑60 Hz.
