The document describes the features and characteristics of a product.
This manual introduces the Y3070 series cloud platform, a weather‑proof PTZ mount suitable for indoor and outdoor installations. It describes the internal AC synchronous motor, waterproof connectors, and optional accessories such as vibration dampers and mounting brackets.
The document covers important safety measures, power requirements, mechanical and electrical parameters, preset position functions, and communication protocols. It also includes a vehicle‑mount example and a list of optional cameras and lenses. This manual is written in Chinese.
| Input voltage | 24V AC 50/60Hz |
|---|---|
| Input power | 18W (including camera and lens) |
| Weight | 4.5 kg |
| Horizontal rotation angle | 0‑355° (adjustable) |
| Horizontal rotation speed | 6°/s (non‑adjustable) |
| Vertical rotation angle | 0‑90° |
| Vertical rotation speed | 8°/s |
| Operating temperature | -20 °C to 60 °C |
| Material | Die‑cast aluminum alloy + polycarbonate |
| Preset positions (YP3070) | 32 positions |
The device operates on 24 V AC at 50/60 Hz and consumes up to 18 W, including the camera and lens.
The YP3070 model provides 32 preset positions for horizontal, vertical, and lens settings.
The Y3070 series uses an internal AC synchronous motor that runs smoothly.
