This document introduces the features and characteristics of the IGBT driver (model TX-KD301) from Beijing Luomuyuan Electronic Technology Co., Ltd., including no need for isolated power supply, negative output when turned off, suitable for driving high-power MOSFET or IGBT in half-bridge, full-bridge, push-pull forward converter, etc.
This guide introduces the TX‑KD301 IGBT driver, covering its main features, recommended applications, and key performance parameters. It includes details on voltage supply, gate capacitance, and current handling capabilities.
The document also provides operating condition limits, pin assignments, and recommended external components such as gate resistors and capacitors. Diagrams of the principle circuit and package dimensions help users integrate the driver into their power conversion designs. This manual is written in Chinese.
| Supply voltage (Vcc) | 14‑16 V |
|---|---|
| Maximum current rating | 20‑60 A |
| Gate charge (Qout) | 600 nC |
| Switching frequency (Fop) | 40 kHz |
| Operating temperature range | -30 °C to 80 °C |
| Storage temperature range | -60 °C to 140 °C |
The driver requires a supply voltage (Vcc) of 14 V to 16 V.
The device can operate up to a switching frequency of 40 kHz.
The driver works from –30 °C up to 80 °C.
It can handle a current of 20 A to 60 A.
