This is a product manual for the MSD series servo motor. It mainly introduces the product model, features, functions, wiring diagram and other information.
This manual provides detailed information for the Leedan MSD series alternating servo motor driver, including electrical specifications, control modes, and safety features. It covers installation, wiring diagrams, and troubleshooting steps for proper operation.
The document also lists dimensional drawings and model variants, helping users select the correct hardware and configure parameters such as input voltage, encoder resolution, and speed limits. This manual is written in Japanese.
| Input Voltage | AC 180‑240 V single‑phase / three‑phase, 50/60 Hz |
|---|---|
| Encoder Resolution | 2500 ppr |
| Control Modes | Position / Speed / Torque |
| Maximum Speed | 0‑255 rpm |
The driver accepts AC 180‑240 V single‑phase or three‑phase, 50/60 Hz.
Press the ALARM RESET button to clear the alarm.
Use the 控制模式切換 switch to select Position, Speed, or Torque mode.
The encoder provides 2500 pulses per revolution.
