This manual begins with extensive safety warnings, covering electrical shock hazards, moisture, heat, proper power sources, and the need for qualified service personnel. It also includes a brief introduction to the mixer’s design and the XDRT extended dynamic range pre‑amp.
The remainder of the document explains level‑setting procedures, the layout of the patch bay, channel strip controls, output sections, and provides numerous wiring diagrams and connection examples for microphones, instruments, line inputs, and speaker systems. Appendices contain a glossary of audio terms, detailed connector information, and support contact details. This manual is written in Japanese.
| Gain range | 0 – 60 dB |
|---|---|
| Line signal handling | +22 dBu |
| Total harmonic distortion | <0.0007 % (20 Hz‑20 kHz) |
| Manufactured in | Woodinville, Washington, USA |
