This document describes the features and characteristics of the Analog Servo Drive 50A20x product produced by Shenzhen Techsoft Intelligent Servo Technology Co., Ltd., including power range, four-quadrant regenerative operation, DIP switch selectable control mode, adjustable current limit, high performance, and high dynamic response.
The 50A20x TM is an analog servo drive designed for DC brushed motors and voice‑coil motors. This reference manual describes its main features, power range, control modes, and hardware protections, helping users integrate the amplifier into motion‑control systems.
Key sections include electrical characteristics (supply voltage, current limits, power consumption), mechanical dimensions, pin‑out tables for connectors P1 and P2, and configuration guidance for DIP switches, analog inputs, and fault handling. Certification information (CE, UL) and installation notes are also provided. This manual is written in Chinese.
| Operating temperature range | 0 °C – 65 °C |
|---|
