Nine9 STFCR 10CA-11 Data Sheet

2008-04-01 (China) Online Service/Technical Support

Nine9 STFCR 10CA-11 Data Sheet - cover page
Brand
Nine9
Category
Other device
Document type
Datasheet
Language
Japanese
Pages
1
File format
PDF
File size
218 KB
Published
12 February, 2012
Updated
01 October, 2023
MD5 checksum
A2F196AE434B9DAF849DF4333717BB23
PDF
Nine9 STFCR 10CA-11 Data Sheet PDF

About this manual

This data sheet presents the STFCR 10CA-11 micrometric adjustable boring tool, highlighting its high interchangeability and fine‑adjustment capability. It lists the tool's advantages over conventional cartridges, such as reduced step boring distance and improved rigidity.

Patents from Taiwan, USA and China are referenced, and various model variants (STFCR, STFPR, CTFPR) are enumerated. The sheet also provides dimensional limits and references to related part numbers. This manual is written in Japanese.

What's inside

  • Features
  • Advantages over conventional tools
  • Patents
  • Model variants
  • Technical limits

Specifications

Maximum step boring distance< 20 mm

Frequently asked questions

What is the maximum step boring distance for the tool?

The step boring distance is limited to less than 20 mm.
