Onkyo HTP-501 2.1-channel speaker system user manual, introduces the features and characteristics of the product, including the connection, placement, power cord attention, tuning the subwoofer volume, etc.
This manual covers safety precautions, package contents and handling instructions for the Onkyo speaker system. It explains the importance of proper grounding, power‑line safety, and how to avoid moisture or heat damage.
Detailed installation guidance is provided for both floor‑standing and wall‑mounted setups, including bracket removal, screw placement, and required clearances. Connection diagrams show how to link the front speakers and subwoofer to a DVD/AV receiver using the supplied RCA cables, and the OUTPUT LEVEL control is described for volume balancing. This manual is written in Chinese.
| Subwoofer Maximum Output Power | 150W (dynamic) |
|---|---|
| Subwoofer Dimensions (W×H×D) | 230 × 425 × 412 mm |
| Subwoofer Weight | 9.1 kg |
| Subwoofer Power Consumption | 105 W |
| Front Speaker Type | 雙向倒相式 |
| Front Speaker Maximum Input Power | 120 W |
| Front Speaker Dimensions (W×H×D) | 140 × 355 × 93 mm |
