This document describes the features and characteristics of the ViewSonic VA2413wm LCD display, including compliance with TCO'03 display standards, ergonomic design, energy-saving mode, electromagnetic radiation and noise emissions control, and environmental requirements.
This manual provides step‑by‑step instructions for unpacking, quick installation, optional wall‑mount setup, and basic operation of the ViewSonic VA2413wm LCD display. It also covers safety warnings, environmental compliance, and warranty information.
Technical specifications, troubleshooting tips, cleaning procedures, and customer‑support contacts are included to help users get the most out of the monitor and keep it in good condition. This manual is written in Chinese.
| Screen size | 23.6" (23.6‑inch) wide diagonal |
|---|---|
| Resolution | 1920 × 1080 (Full HD) |
| Panel type | TFT active‑matrix WUXGA LCD |
| Pixel pitch | 0.2715 mm |
| Input signals | RGB analog (0.7/1.0 Vp‑p, 75 Ω) |
| Power supply | 100‑240 VAC, 50/60 Hz (auto‑switching) |
| Typical power consumption | 47 W (active), ≤0.5 W (standby) |
| Dimensions (W × H × D) | 563.6 mm × 417.2 mm × 260.8 mm |
| Weight | 11.68 lb (5.3 kg) |
Sit at least 18 inches away from the LCD display.
The monitor works with a universal 100‑240 VAC, 50/60 Hz power source.
