This document introduces the features and technical specifications of Inmidas Technology's MIDAS series MEO-100 Ethernet Fiber Bridge, including support for IEEE 802.3Q VLAN frames and long frames transmission, DHCP packet filtering, and built-in 32Kbytes MAC address storage space.
The MEO-100 Ethernet fiber optic bridge from Inmidas Technology provides a 10/100 M Ethernet interface and a fiber optic port for extending LANs over long distances. It supports IEEE 802.3Q VLAN frames, DHCP packet filtering, and offers configurable line rates via DIP switches.
The manual includes a product overview, front‑ and rear‑panel descriptions, wiring diagrams, installation steps, and a detailed fault‑diagnosis guide. It also explains how to set clock modes, DIP‑switch functions, and how to use the built‑in test LEDs for troubleshooting. This manual is written in Chinese.
