The VLT HVAC Drive FC102 series is a variable frequency drive (VFD) specifically designed for HVAC applications. It provides up to 98% efficiency, has a sleep mode, automatic energy optimization, and flow compensation. The VLT HVAC Drive FC102 series is also modular, allowing for upgrades as needed, and has IP55 protection, eliminating the need for an external cabinet.
The VLT FC102 HVAC drive is a next‑generation frequency transformer designed for building automation and HVAC applications. It offers high efficiency (up to 98%), multiple control modes, and an IP55 protection rating, helping reduce energy consumption and operating costs.
The manual covers installation procedures, control panel functions, fire‑control mode for emergency situations, and detailed communication interfaces (e.g., BACnet, Modbus). It also provides guidance on energy‑saving features, PID control, and troubleshooting, ensuring reliable operation in various building environments. This manual is written in Chinese.
| Protection rating | IP55 |
|---|---|
| Maximum efficiency | 98% |
| Ambient temperature range | up to 50 °C |
The FC102 HVAC drive is rated IP55, providing protection against dust and water.
The drive achieves up to 98% efficiency.
