HLP-SV series inverter user manual, which introduces the product features, installation, wiring, operation and maintenance
This manual introduces the HLP‑SV series frequency converters, describing safety warnings, required protective measures, and general handling precautions. It emphasizes the high‑voltage nature of the device and the need for qualified personnel during installation and service.
The document covers storage, installation environment, wiring diagrams, LCP operator functions, parameter settings, functional descriptions, and detailed maintenance and troubleshooting procedures, including fault codes and recommended fuse selections. This manual is written in Chinese.
| Model | HLPSV0D75 |
|---|---|
| Power | 0.75 kW |
| Input Voltage | 1×200‑240V |
| Recommended Fuse (0.75 kW model) | 25 A gG |
| Maximum IT Main Power Voltage | 440 V |
Always press the OFF (stop) key before changing any parameters, and ensure the converter is disconnected from the main power when not in use.
A 25 A gG type fuse is recommended for the 0.75 kW model.
The maximum allowed voltage for the IT main power connection is 440 V.
