D6600 is a communication device with a simple and easy-to-use panel keyboard and basic configuration programming function. It can communicate through the serial port connected to the computer. It supports multiple communication formats, such as 4+2 Pulse, C&K, C&K III, Contact ID, etc. It can view alarm history records and perform troubleshooting.
This manual describes how to use the D6600 panel, including navigation of menus, saving changes, and exiting to normal display mode. It also explains the COM3 interface pinout and how to configure communication parameters such as baud rate, data bits, parity, and stop bits.
Additional sections cover basic programming examples, compatible formats (e.g., 42 Pulse, C&K), and a troubleshooting guide that helps resolve common issues like mismatched COM3 settings or power indicator problems. This manual is written in Chinese.
| COM3 Baud Rate | 7 |
|---|---|
| COM3 Data Bits | 8 |
| COM3 Parity | 0 (None) |
| COM3 Stop Bits | 1 |
| COM3 Character Length | 68 |
| COM3 Character Tail | D |
| COM3 Output Format | 1 |
Set the COM3 baud rate to the desired value, e.g., 7, as shown in the manual.
If the Power light is off, check the AC supply and connections.
