SZ05-ZIGBEE wireless communication module is an embedded wireless communication module that integrates RF transceiver and microprocessor compliant with ZIGBEE protocol standard. It has the advantages and characteristics of long communication distance, strong anti-interference ability, flexible networking, and reliable performance. The module can achieve transparent transmission of data between devices in point-to-point, one-to-many, and many-to-many modes, and can form a network structure of star, tree, and mesh.
The SZ05‑ZBEE is an embedded wireless communication module that complies with the Zigbee protocol, offering long‑range transmission, strong anti‑interference, flexible networking and reliable performance. It supports point‑to‑point, point‑to‑multiple and multiple‑to‑multiple data transfer and can be configured as a coordinator, router or end node.
The manual covers functional description, technical specifications, pin‑out and connector details, configuration parameters (channel, network type, node type, MAC address, baud rate, etc.), data sending modes and frame formats, installation dimensions, LED status indicators, and safety precautions for proper use. This manual is written in Chinese.
