This is a specification sheet for an LED light. It includes information such as the power of the LED light, the number of LEDs, the color of the light, the color temperature, the color rendering index, the lifespan, the luminous flux, the beam angle, the material, the net weight, the gross weight, the packaging dimensions, the packaging specifications, the real picture, the outer dimensions, the working environment temperature, the humidity, the storage conditions, the rated voltage, the input current, the protection level, etc.
The LJ-SSP-W100-220 is a 100 W white LED lighting fixture designed for indoor use. It offers two color‑temperature options (3000 K and 6500 K) with a luminous flux of 8400 lm and a wide 120° beam angle. The unit measures 685 × 310 × 200 mm, weighs 5.1 kg net (5.4 kg gross), and complies with IP67 protection.
Technical data include a rated voltage of AC 220 V, input current of 0.43 A, and an operating temperature range of –37 °C to 55 °C. Storage conditions allow –40 °C to 80 °C and up to 95 % humidity. The product is rated for a lifetime exceeding 40 000 hours and is supplied with 270 LEDs per unit. This manual is written in Chinese.
| Power | 100 W |
|---|---|
| LED Quantity | 270 pcs |
| Color Temperature | 3000 K / 6500 K |
| Luminous Flux | 8400 lm |
| Beam Angle | 120° |
| Dimensions (L×W×H) | 685 × 310 × 200 mm |
| Net Weight | 5.1 kg |
| Gross Weight | 5.4 kg |
| Rated Voltage | AC 220 V |
| Input Current | 0.43 A |
| IP Rating | IP67 |
| Operating Temperature | -37 °C to 55 °C |
| Storage Temperature | -40 °C to 80 °C |
| Lifetime | >40 000 h |
The fixture is rated at 100 W.
It is available in white with 3000 K or 6500 K color temperature.
The product meets IP67 protection.
The unit can operate from –37 °C up to 55 °C.
