Advantech PCL-812 / PCL-833 Installation Manual

This document is the installation manual for PCL-812 and PCL-833 cards, compatible with Windows XP. The manual includes installation steps, driver download, and jumper settings on the cards.

Advantech PCL-812 / PCL-833 Installation Manual - cover page
Brand
安裝
Category
Other device
Document type
Installation Guide
Language
English
Pages
16
File format
PDF
File size
1.3 MB
Published
12 January, 2012
Updated
29 September, 2023
MD5 checksum
74697C5542E249646C4948FF976F9556
PDF
Advantech PCL-812 / PCL-833 Installation Manual PDF

About this manual

This manual provides step‑by‑step instructions for installing and configuring the Advantech PCL-812 and PCL‑833 data acquisition cards. It includes driver installation for Windows XP, setting base I/O addresses, and configuring interrupt levels.

The document also details handling precautions, shipping inspection guidelines, and jumper/DIP‑switch settings to ensure reliable operation of the cards in a PC environment.

What's inside

  • Driver Installation
  • Device Manager Overview
  • Base I/O Address Settings
  • Interrupt Level Configuration
  • Jumper and DIP Switch Settings
  • Handling and Static Precautions
  • Shipping Inspection and Warranty

Specifications

Input voltage range0‑10 V
Default interrupt channel5
Base address range (hex)200h‑20Fh
Default interrupt level7

Frequently asked questions

What safety precaution should I take before handling the card?

Discharge any static electricity by touching grounded metal and handle the board by its edges.

Download PDF (1.3 MB)
