Secospace USG2100/2200/5100 BSR/HSR Security Router is a new generation of multi-service security router, which is designed to meet the needs of modern enterprises for integrated security, routing, switching, wireless and voice services. This product series has the characteristics of multi-service concurrent access, end-to-end integrated integration, rich routing and four-way connection.
The Secospace USG2100/2200/5100 BSR/HSR series is a next‑generation multi‑service security router gateway that integrates routing, switching, wireless, and voice functions in a modular, scalable device. It targets small‑to‑medium businesses, branch offices and SOHO users, offering high‑performance security features such as stateful firewall, VPN, NAT, IPS and anti‑spam.
The manual provides an overview of the product series, key features, typical network deployments, and detailed hardware specifications including interface types, expansion slots, dimensions, power requirements and environmental design. This manual is written in Chinese.
| Fixed WAN ports | 1 × 10/100 |
|---|---|
| Fixed LAN ports | 8 × 10/100 |
| Maximum interface density | 13 |
| Expansion slots | 1 MIC |
| USB interfaces | 1 (v2.0) |
| VPN function | Optional |
| Wi‑Fi function | Supported on higher models |
| Rated input voltage | AC 100‑240 V, 50/60 Hz |
| Dimensions (W×D×H) | 420 mm × 255 mm × 44.45 mm |
| Weight | 5.0 kg |
