XC-SP8GM series is a photoelectric switch product of Higar. It has the characteristics of anti-frequency and sunlight noise interference, exquisite short tube type, built-in amplifier, and can effectively resist harsh working environment.
The XC SP8GM series sensor is designed for harsh work environments with built‑in amplifier, short‑circuit and polarity protection, and an infrared LED light source. It features a red LED indicator for operation status and complies with IEC IP67 protection rating.
The manual includes wiring diagrams, supply requirements of DC 10‑30 V with up to 10 % ripple, a maximum load current of 100 mA, and a response time of 5 ms. It also describes connector types, cable specifications, and environmental lighting limits for reliable performance. This manual is written in Japanese.
| Supply voltage | DC 10‑30 V |
|---|---|
| Ripple tolerance | ≤10 % |
| Load current | ≤100 mA |
| Output type | NPN/PNP, NO & NC |
| LED indicator | Red LED |
| Protection | Short‑circuit and polarity protection |
| Light source | Infrared LED |
| IP rating | IP67 |
The sensor operates on a DC supply voltage of 10 to 30 V.
The output includes short‑circuit and polarity protection.
The sensor is rated IEC IP67.
