This manual introduces the appearance size, electrical connection, parameter setting and application examples of E380 series universal inverters.
The document describes how to operate the E380 series frequency converter, including panel start/stop functions, external terminal control, and multi‑speed settings. It explains the V/F control method and the basic wiring diagrams needed for installation.
Detailed procedures cover panel control, external terminal connections (VC1, VC2, FWD, REV), multi‑speed configuration up to 15 steps, and optional modification options for advanced applications. Safety notes and parameter settings are also included. This manual is written in Chinese.
| External frequency input voltage range | 0‑10 V |
|---|---|
| Speed steps | 15 |
| Control method | V/F |
Use the panel control start/stop function as described in section 10.1 of the manual.
Set the frequency via the external terminal VC2 (0‑10 V) as explained in section 10.2.
The converter can be configured for up to 15 speed steps.
