Fairchild NC7SZ32 TinyLogic UHS 2-Input OR Gate Datasheet

NC7SZ32 is a single 2-input OR Gate from Fairchild’s Ultra High Speed Series of TinyLogic.

Fairchild NC7SZ32 TinyLogic UHS 2-Input OR Gate Datasheet - cover page
Brand
NC7SZ32
Category
Other Electronics
Document type
Datasheet
Language
English
Pages
9
File format
PDF
File size
105 KB
Published
04 January, 2012
Updated
30 September, 2023
MD5 checksum
1FAC572CB7520CC28A9F1E68BFF3ADCE
PDF
Fairchild NC7SZ32 TinyLogic UHS 2-Input OR Gate Datasheet PDF

About this manual

The NC7SZ32 is a single 2‑input OR gate from Fairchild’s TinyLogic™ Ultra‑High‑Speed (UHS) series. It is offered in compact SOT23, SC70, and lead‑less MicroPak packages and operates over a wide VCC range with low static power.

The document provides absolute maximum ratings, recommended operating conditions, DC and AC electrical characteristics, package dimensions, and tape‑and‑reel handling details, along with Fairchild’s life‑support policy disclaimer.

What's inside

  • General Description
  • Features
  • Absolute Maximum Ratings
  • Recommended Operating Conditions
  • DC Electrical Characteristics
  • AC Electrical Characteristics
  • Ordering Code
  • Tape and Reel Specification
  • Physical Dimensions
  • Life Support Policy

Specifications

Propagation delay (typ)2.4 ns into 50 pF at 5V VCC
Output drive current+24 mA at 8V VCC
Operating voltage range1.65 V to 5.5 V VCC
Input voltage toleranceUp to 6 V independent of VCC

Frequently asked questions

What is the recommended operating voltage range for the NC7SZ32?

The device is specified to operate over a VCC range of 1.65 V to 5.5 V.

How much output current can the NC7SZ32 drive?

It can source up to +24 mA when powered at 8 V VCC.

What packages are available for the NC7SZ32?

The part is offered in 5‑lead SOT23 (MA05B), 5‑lead SC70 (MAA05A), and 6‑lead MicroPak (MACO6A) packages.

Is the NC7SZ32 suitable for life‑support applications?

No. Fairchild states the product is not authorized for use as a critical component in life‑support devices without explicit written approval.
