This product is a closed loop stepping system that combines the ease of use of stepping motors with the reliability of servomotors, making the system faster and smaller.
The SANMOTION PB series combines the ease‑of‑use of stepping motors with the reliability of servomotors, offering high speed positioning, high torque at low speeds, stable stand‑still, and energy‑saving operation. It supports multiple control methods such as general‑purpose I/O, pulse‑train input, RS‑485 serial communication, and PC‑based multi‑axis control.
The system includes an amplifier, motor, optional gearboxes, harmonic gear, and electromagnetic brake. Various interface types (R: RS‑485+PIO, P: Pulse Stream, M: Multi‑axis) and power inputs (AC or DC) are available, along with a range of optional cables and PC interface software for parameter setting and monitoring. Safety cautions and installation guidelines are provided.
| Encoder Type 1 | 200P/R INC |
|---|---|
| Motor Excitation Current | 1A |
| Power Input A | AC Power Source |
| Interface Type R | RS-485+PIO |
| Vibration Rating | 15 G (10‑70 Hz) |
The PB series can be powered by an AC power source (Power Input A) or a DC power source (Power Input D).
Control methods include general‑purpose I/O, pulse‑train input, RS‑485 serial communication, and PC‑based multi‑axis control via the bundled software.
Read the instruction manual, avoid using the product in vibrating environments, do not retrofit or modify the equipment, and contact Sanyo Denki for medical or critical applications.
