This document introduces the basic information of A4P series servo drivers, including technical characteristics, installation dimensions, electrical parameters, etc., and also provides product CE and UL certification information.
This manual describes the conformity of the Panasonic MINAS A4P servo system to European EC Directives and UL standards. It explains the applicable low‑voltage, EMC and safety directives, lists the required certifications, and provides guidance for achieving compliance in machine designs.
The document also details installation requirements such as power‑supply voltage ranges, noise‑filter placement, ground‑fault protection, overload limits, and optional peripheral equipment. Safety cautions, after‑sale service information, and references to technical data downloads are included.
| Power supply (100 V type) | Single phase, 100 V ±15 % (115 V) 50/60 Hz |
|---|---|
| Insulated DC supply | DC12‑24 V with CE marking or EN60950 compliance |
| Over‑load protection activation | Effective current > 115 % of rated current |
| Installation category | Over‑voltage category II (EN 50178) |
Install a noise filter between the power supply and the driver; for multi‑axis applications use one filter per power supply, and follow the wiring diagram provided.
