HBM HE371B / HEM371B / HES371B Integration Broadband Amplifier Manual

This document describes the features and characteristics of the RF/microwave integrated amplifier series products in the Shijiazhuang City 179 Mailbox 76 Sub-Box, including performance parameters such as frequency range, gain, noise figure, input-output VSWR, etc.

HBM HE371B / HEM371B / HES371B Integration Broadband Amplifier Manual - cover page
Brand
HE371B/HEM371B/HES371B
Category
Other Electronics
Document type
User Manual
Language
Japanese
Pages
1
File format
PDF
File size
145 KB
Published
29 December, 2011
Updated
28 September, 2023
MD5 checksum
3EE6A33914F87DEB7B7E57F5BB00E111
PDF
HBM HE371B / HEM371B / HES371B Integration Broadband Amplifier Manual PDF

About this manual

This manual describes the technical specifications of the HBM integration broadband amplifier, including frequency range, gain, VSWR, and output power. It also outlines the operating temperature limits and supply requirements.

Installation guidance covers connector options such as SMA output and compatibility with HP UT0-510, as well as mechanical dimensions and mounting procedures. Reference tables provide performance curves for various frequencies. This manual is written in Japanese.

What's inside

  • Performance Specifications
  • Gain
  • VSWR
  • Output Power
  • Operating Conditions
  • Installation Guide
  • Connector Options
  • Mechanical Dimensions

Specifications

Small signal gain15.0 dB
Input VSWR2.0:1
Output VSWR2.0:1
Output power2.0 dBm
Maximum operating temperature125 °C

Frequently asked questions

What is the input VSWR rating?

The input VSWR is rated at 2.0 : 1.

What is the maximum output power?

The maximum output power is 2.0 dBm.
