The product is the hydraulic servo control brake cylinder produced by SAFIM company. It has the characteristics of high braking pressure, low pedal force, simple hydraulic circuit, compact appearance, etc.
This manual describes the SAFIM Liquid Press servo control system, a hydraulic servo brake cylinder used for industrial machines. It outlines the advantages such as high brake pressure, low pedal force, simple hydraulic circuit, compact design, built‑in safety valve, and customizable pressure limit valves.
The document includes technical specifications, installation diagrams, operation procedures, safety precautions, and detailed ordering information for various cylinder models and configurations. This manual is written in Chinese.
| Supply flow | 3.5‑22 L/min |
|---|---|
| Operating temperature (mineral oil) | -20 °C to 90 °C |
| Operating temperature (brake fluid) | -20 °C to 100 °C |
| Maximum allowable back pressure | 0.5 bar |
| Maximum non‑load supply pressure | 1.5 bar |
| Maximum brake pressure | 150 bar |
The maximum brake pressure is 150 bar.
For mineral oil the range is –20 °C to 90 °C; for brake fluid it is –20 °C to 100 °C.
The system can supply hydraulic fluid at 3.5 to 22 L per minute.
A safety adjustment valve can be installed to limit the brake system pressure.
