The KVFC+ series is a variable frequency drive produced by Kasuga Electric Co., Ltd. It features high torque, high precision, and wide speed range, meeting the demand for high-performance general-purpose VFDs. It adopts advanced control methods, with fast current limiting, anti-trip performance, and optimized energy-saving operation mode to adapt to harsh environmental conditions and improve product reliability. The VFD also incorporates practical PI and simple PLC functions, flexible input-output terminals, and pulse frequency setting, providing modern manufacturing customers with lower system costs and higher system reliability.
The KVFC+ series inverter from Kasuga offers high torque, high precision and wide speed range control for various industrial applications. The manual covers pre‑use checks, installation, wiring, digital operator KP‑M1 usage, running procedures, function parameter selection, protection actions and maintenance.
Technical specifications, optional accessories and communication protocol details are also included, along with wiring diagrams, parameter tables and example commands for master‑slave communication. This manual is written in Chinese.
| Input voltage | 200 V or 400 V three‑phase |
|---|
The warranty period is one year from the date of purchase.
Under normal conditions the filter electrolytic capacitor should be replaced every five years.
Use a cable with a cross‑section of 0.3 mm² to 0.75 mm² for the control circuit.
