This document introduces the product lineup of laying construction and maintenance measurement instruments, including various light sources and optical power meters, as well as high-performance and easy-to-use OTDRs. The products are characterized by their compact and lightweight design, high accuracy, and high work efficiency.
The AQ1100 is a compact optical power meter and multi‑field tester that supports a wide wavelength range from 750 nm to 1700 nm, including the common 1310 nm and 1550 nm bands. It offers both continuous‑wave (CW) and chopped (CHOP) measurement modes with power ranges from –50 dBm to +10 dBm.
The device includes Ethernet (10BASE‑T/100BASE‑TX) and USB interfaces, a 5‑inch color LCD, and a rechargeable battery that provides up to several hours of operation. It complies with safety and EMC standards such as EN61010‑1, EN60825‑1 and IEC 61000 series. This manual is written in Japanese.
| Measurement wavelength range | 750 nm – 1700 nm (1310 nm / 1550 nm) |
|---|---|
| Power measurement range (CW) | -50 dBm to +10 dBm |
| Display resolution | 0.01 dB |
| Ethernet interface | 10BASE‑T / 100BASE‑TX |
| Battery voltage | 100‑240 V AC input, internal rechargeable battery |
It measures from 750 nm up to 1700 nm, including the 1310 nm and 1550 nm bands.
The device provides an Ethernet port supporting 10BASE‑T and 100BASE‑TX.
The CW power range is from –50 dBm to +10 dBm.
The display can resolve changes as small as 0.01 dB.
